7.1 Motors
7-17
Wiring
7
•CACR-JU028ACA, -JUM23CA, -JUM24CA, -JUM25CA, -JU014DCA
Note: No polarity for connection to the brake terminals.
SERVOPACK End
(CN8/CN18/CN28)
Motor End
Pin No. Signal Name Pin No. Signal Name
A1 U A U
B1 V B V
B2 W C W
A2 D
Motor End
Pin No. Signal Name
Brake 1 Brake
Brake 2 Brake
