YASKAWA CIMR-JA Series

Table C.2 EN 61800-3 Category C1 Filters
Drive
CIMR-Jo
Filter Data (Manufacturer: Schaffner)
Type
Rated
Current
(A)
Weight
(kg)
Dimensions
[W x L x H] (mm)
Y x X
Drive
Mounting
Screw A
Filter
Mounting
Screw
200 V Single-Phase Units
BA0001 FS23638-10-07 10 0.44 71 x 169 x 45 51 x 156 M4 M5
BA0002 FS23638-10-07 10 0.44 71 x 169 x 45 51 x 156 M4 M5
BA0003 FS23638-10-07 10 0.44 71 x 169 x 45 51 x 156 M4 M5
BA0006 FS23638-20-07 20 0.75 111 x 169 x 50 91 x 156 M4 M5
BA0010 FS23638-20-07 20 0.75 111 x 169 x 50 91 x 156 M4 M5
200 V Three-Phase Units
2A0001 FS23637-8-07 8 0.4 71 x 169 x 40 51 x 156 M4 M5
2A0002 FS23637-8-07 8 0.4 71 x 169 x 40 51 x 156 M4 M5
2A0004 FS23637-8-07 8 0.4 71 x 169 x 40 51 x 156 M4 M5
2A0006 FS23637-8-07 8 0.4 71 x 169 x 40 51 x 156 M4 M5
2A0008 FS23637-14-07 14 0.58 111 x 169 x 45 91 x 156 M4 M5
2A0010 FS23637-14-07 14 0.58 111 x 169 x 45 91 x 156 M4 M5
2A0012 FS23637-14-07 14 0.58 111 x 169 x 45 91 x 156 M4 M5
2A0018 FS23637-24-07 24 0.9 144 x 174 x 50 120 x 156 M4 M5
2A0020 FS23637-24-07 24 0.9 144 x 174 x 50 120 x 156 M4 M5
400 V Three-Phase Units
4A0001 FS23639-5-07 5 0.5 111 x 169 x 45 91 x 156 M4 M5
4A0002 FS23639-5-07 5 0.5 111 x 169 x 45 91 x 156 M4 M5
4A0004 FS23639-5-07 5 0.5 111 x 169 x 45 91 x 156 M4 M5
4A0005 FS23639-10-07 10 0.7 111 x 169 x 45 91 x 156 M4 M5
4A0007 FS23639-10-07 10 0.7 111 x 169 x 45 91 x 156 M4 M5
4A0009 FS23639-10-07 10 0.7 111 x 169 x 45 91 x 156 M4 M5
4A0011 FS23639-15-07 15 0.9 144 x 174 x 50 120 x 161 M4 M5
