YASKAWA CIPR-GA50C series Technical Manual

5.2 European Standards
186 YASKAWA SIEPC71061753C GA500 Technical Manual
Table 5.13 External EMC Noise Filter (2xxxA)
Drive model EMC Noise Filter Model Quantity Manufacturer
2001 FS23637-8-07 1 Schaffner
2002 FS23637-8-07 1 Schaffner
2004 FS23637-8-07 1 Schaffner
2006 FS23637-8-07 1 Schaffner
2008 FS23637-14-07 1 Schaffner
2010 FS23637-14-07 1 Schaffner
2012 FS23637-14-07 1 Schaffner
2018 FS23637-24-07 1 Schaffner
2021 FS23637-24-07 1 Schaffner
2030 FS5973-35-07
*1
1 Schaffner
2042 FS5973-60-07
*1
1 Schaffner
2056 FS5973-100-07
*1
1 Schaffner
2070 FS5973-100-07
*1
1 Schaffner
2082 RTEN-5200 1 TDK
*1 When you install an external EMC noise filter, change the terminals or use the junction terminal.
Table 5.14 External EMC Noise Filter (4xxxA)
Drive model EMC Noise Filter Model Quantity Manufacturer
4001 FS23639-5-07 1 Schaffner
4002 FS23639-5-07 1 Schaffner
4004 FS23639-5-07 1 Schaffner
4005 FS23639-10-07 1 Schaffner
4007 FS23639-10-07 1 Schaffner
4009 FS23639-10-07 1 Schaffner
4012 FS23639-15-07 1 Schaffner
4018 FS5972-35-07
*1
1 Schaffner
4023 FS5972-35-07
*1
1 Schaffner
4031 FS5972-60-07
*1
1 Schaffner
4038 FS5972-60-07
*1
1 Schaffner
4044 RTEN-5100 1 TDK
4060 RTEN-5100 1 TDK
*1 When you install an external EMC noise filter, change the terminals or use the junction terminal.
■ DC Reactors
To comply with EN 61000-3-2 on drive models 2001 to 2006, and 4001 to 4004, install a DC reactor when you
use an internal or external EMC filter. Refer to Table 5.15 to select the correct DC reactor.
Table 5.15 DC Reactors for Harmonic Suppression (Manufacturer: Yaskawa Electric)
Drive Model
DC reactor
Manufacturer: Yaskawa
Model Rating
2001 - 2006 UZDA-B 5.4A, 8mA
4001 - 4004 UZDA-B 3.2A, 28mA
