11.10 H: Terminal Functions
YASKAWA SIEPC71061753C GA500 Technical Manual 411
Setting Value Function Description Ref.
119 Torque Detection 2 (N.
O.)
The terminal activates when the drive detects overtorque or undertorque.
ON : The output current/torque exceeds the torque value set with L6-05 [Torque Detection Level 2], or the level
has dropped and remained in this state longer than the time set with L6-06 [Torque Detection Time 2].
667
11A !During Reverse
The terminal deactivates when the motor operates in the reverse direction.
ON : The motor is operating in the forward direction or the motor stopped.
OFF : The motor is operating in the reverse direction.
667
11B During Baseblock (N.O.)
The terminal activates during baseblock. When the drive is in baseblock, the drive output transistor stops switching
and does not make DC bus voltage.
ON : During baseblock
OFF : The drive is not in baseblock.
667
11C !Motor 2 Selected
The terminal deactivates when motor 2 is selected.
ON : Motor 1 Selection
OFF : Motor 2 Selection
667
11E !Executing Auto-Restart
The terminal deactivates when the Auto Restart function is trying to restart after a fault.
667
11F !Motor Overload Alarm
(oL1)
The terminal deactivates when the electronic thermal protection value of the motor overload protective function is
a minimum of 90% of the detection level.
667
120 !Drive Overheat Pre-
Alarm (oH)
The terminal deactivates when the drive heatsink temperature is at the level set with L8-02 [Overheat Alarm
Level].
667
121 !Safe Torque OFF
The terminal deactivates (safety stop state) when the safety circuit and safety diagnosis circuit are operating
correctly and when terminals H1-HC and H2-HC are OFF (Open).
ON : Safety circuit fault or RUN/READY
OFF : Safety stop state
667
122 !Mechanical Weakening
Detection
The terminal deactivates when the drive detects mechanical weakening.
667
12F !Maintenance
Notification
The terminal deactivates when drive components are at their estimated maintenance period.
Tells you about the maintenance period for these items:
• IGBT
• Cooling Fan
• Capacitor
• Soft charge bypass relay
667
130 !During Torque Limit
The terminal deactivates when the torque reference is the torque limit set with L7 parameters or H3-02 or H3-10
[MFAI Function Selection].
667
137 !During Frequency
Output
The terminal deactivates when the drive outputs frequency.
ON : The drive is not outputting frequency.
OFF : The drive is outputting frequency.
667
138 !Drive Enabled
This terminal deactivates when the H1-xx = 16A [Drive Enable] terminal deactivates.
667
139 !Watt Hour Pulse Output
Outputs the pulse that shows the watt hours.
667
13C !LOCAL Control
Selected
The terminal deactivates when the Run command source or frequency reference source is LOCAL.
ON : REMOTE
OFF : LOCAL
667
13D !During Speed Search
The terminal deactivates when the drive does speed search.
667
13E !PID Feedback Low
The terminal deactivates when the drive detects FbL [PID Feedback Loss].
667
13F !PID Feedback High
The terminal deactivates when the drive detects FbH [Excessive PID Feedback].
667
14A !During KEB Ride-Thru
The terminal deactivates when the drive executes the KEB Ride-Thru function.
667
