12.7 F: Options
618 YASKAWA SIEPC71061753C GA500 Technical Manual
■ F6-63: DeviceNet Network MAC ID
No.
(Hex.)
Name Description
Default
(Range)
F6-63
(03DE)
DeviceNet Network MAC
ID
Sets the function to see the actual DeviceNet MAC address using the keypad. This parameter
functions as a monitor only.
0
(0 - 63)
■ F6-64 to F6-67: Dynamic Out Assembly 109 Param1 to 4
No.
(Hex.)
Name Description
Default
(Range)
F6-64 to F6-67
(03DF - 03E2)
Dynamic Out Assembly
109 Param 1 to 4
Sets Configurable Outputs 1 to 4 written to the MEMOBUS register.
0000H
(0000H - FFFFH)
■ F6-68 to F6-71: Dynamic In Assembly 159 Param 1 to 4
No.
(Hex.)
Name Description
Default
(Range)
F6-68 to F6-71
(03E3, 03E4,
03C7, and 03C8)
Dynamic In Assembly 159
Param 1 to 4
Sets Configurable Inputs 1 to 4 read from the MEMOBUS register.
0000H
(0000H - FFFFH)
■ F6-72: PowerLink Node Address
No.
(Hex.)
Name Description
Default
(Range)
F6-72
(081B)
PowerLink Node Address
Sets the node ID for PowerLink communication.
0
(0 - 255)
■ F7-01: IP Address 1
No.
(Hex.)
Name Description
Default
(Range)
F7-01
(03E5)
IP Address 1
Sets the first octet of the IP Address for the device that is connecting to the network. Restart the
drive after you change this parameter.
192
(0 - 255)
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure to set a different IP address for each drive on the
network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to 4].
■ F7-02: IP Address 2
No.
(Hex.)
Name Description
Default
(Range)
F7-02
(03E6)
IP Address 2
Sets the second octet of the IP Address for the device that is connecting to the network. Restart the
drive after you change this parameter.
168
(0 - 255)
Note:
When F7-13 = 0 [Address Mode at Startup = Static]:
• Use parameters F7-01 to F7-04 [IP Address 1 to 4] to set the IP Address. Be sure to set a different IP address for each drive on the
network.
• Also set parameters F7-05 to F7-12 [Subnet Mask 1 to 4, Gateway Address 1 to 4].
■ F7-03: IP Address 3
No.
(Hex.)
Name Description
Default
(Range)
F7-03
(03E7)
IP Address 3
Sets the third octet of the IP Address for the device that is connecting to the network. Restart the
drive after you change this parameter.
1
(0 - 255)
