3.2 Operating Procedures for Utility Functions
3.2.35 ZONE Table Edit/Save (FnB04)
3-117
3
Utility Functions
Saving ZONE Tables
The operating procedure for saving ZONE tables is shown below.
Step Operation Result
1
Display the ZONE table editing
screen.
2
Press the key to view the
ZONE table save screen.
3
Move the cursor with the
keys to select “STORE”.
Note: Selecting “CANCEL” and pressing
the key will return the display
to the ZONE table editing screen.
4
Press the key to start saving
the ZONE table to flash memory.*
Do not turn off the control power
supply until saving has been com-
pleted normally.
5
When saving to flash memory has
been completed normally, the dis-
play returns to the ZONE table edit-
ing screen.
6
Press the key to return to the
Utility Function Mode main menu.
* If the key is pressed in an operation prohibited state, “Error.” is displayed for
approximately 2 seconds and then the display returns to the ZONE table editing
screen. In this case, make the setting again by referring to Preparation on page 3-
114.
