xxiv
Installation Precautions
Do not hold onto the front cover or connectors when you move a
SERVOPACK.
There is a risk of the SERVOPACK falling.
A SERVOPACK or Servomotor is a precision device. Do not drop
it or subject it to strong shock.
There is a risk of failure or damage.
Do not subject connectors to shock.
There is a risk of faulty connections or damage.
If disinfectants or insecticides must be used to treat packing
materials such as wooden frames, plywood, or pallets, the pack-
ing materials must be treated before the product is packaged,
and methods other than fumigation must be used.
Example: Heat treatment, where materials are kiln-dried to a core
temperature of 56°C for 30 minutes or more.
If the electronic products, which include stand-alone products and
products installed in machines, are packed with fumigated wooden
materials, the electrical components may be greatly damaged by
the gases or fumes resulting from the fumigation process. In partic-
ular, disinfectants containing halogen, which includes chlorine, fluo-
rine, bromine, or iodine can contribute to the erosion of the
capacitors.
Do not overtighten the eyebolts on a SERVOPACK or Servomotor.
If you use a tool to overtighten the eyebolts, the tapped holes may
be damaged.
Install the Servomotor or SERVOPACK in a way that will support
the mass given in technical documents.
Install SERVOPACKs, Servomotors, regenerative resistors, and
External Dynamic Brake Resistors on nonflammable materials.
Installation directly onto or near flammable materials may result in
fire.
Provide the specified clearances between the SERVOPACK and
the control panel as well as with other devices.
There is a risk of fire or failure.
Install the SERVOPACK in the specified orientation.
There is a risk of fire or failure.
Do not step on or place a heavy object on the product.
There is a risk of failure, damage, or injury.
Do not allow any foreign matter to enter the SERVOPACK or Ser-
vomotor.
There is a risk of failure or fire.
To Next Page
