2.2 Monitors
2.2.1 Monitor Items
2-8
Un00B
Power Consumed by DB Resistance
(percentage of processable power at DB
activation: displayed in cycles of 10 sec-
onds)
%
Un00C Input Reference Pulse Counter Reference units
Un00D Feedback Pulse Counter Encoder pulses
Un00E
Fully-Closed Loop Feedback Pulse
Counter
Encoder pulses
Un010
Upper Limit Setting of Motor Maximum
Speed/Upper Limit Setting of Encoder
Output Resolution
−
Un011 Polarity Sensor Signal Monitor −
Un012 Total Run Time 100 ms
Un013 Feedback Pulse Counter Reference units
Un014
Effective Gain Monitor (gain settings 1 =
1, gain settings 2 = 2)
–
Un015 Safety I/O Signal Monitor –
Un020 Rated Motor Speed
min
-1
Un021 Maximum Motor Speed
min
-1
Un025
SERVOPACK Installation Environment
Monitor
%
Un026
*1
Servomotor Installation Environment
Monitor
%
Un027 Built-in Fan Remaining Life Ratio %
Un028 Capacitor Remaining Life Ratio %
Un029
Surge Prevention Circuit Remaining Life
Ratio
%
Un02A
Dynamic Brake Circuit Remaining Life
Ratio
%
Un02F Overheat Protection Input 0.01 V
Un030
*2
Current Backlash Compensation Value 0.1 reference units
Un031
*2
Backlash Compensation Value Setting
Limit
0.1 reference units
Un032 Power Consumption W
Un033 Consumed Power 0.001 Wh
Un034 Cumulative Power Consumption Wh
Un040 Absolute Encoder Multiturn Data –
Continued on next page.
Continued from previous page.
Un No. Content of Display Unit
