2.10 o: Operator Related Settings
234 YASKAWA ELECTRIC TOEP C710687 03B FSDrive-MV1000 Parameter Guide
Table 2.30 LO/RE Key and b1-07
n o2-02: STOP Key Function Selection
Determines if the STOP key on the digital operator can still be used to stop drive operation when the drive is being
controlled from a remote source (i.e., not from digital operator).
Setting 0: Disabled
Setting 1: Enabled
The STOP key can be used to terminate drive operation, even if the Run command source is not assigned to the digital
operator. If the drive is stopped by pressing the STOP key, the Run command must be re-input to restart the drive.
n
o2-03: User Parameter Default Value
After drive parameters are set up completely, the values set can be saved as user-set default values using parameter
o2-03. Once this has been done, the “Initialize Parameters” parameter (A1-03) will offer the choice of “1110: User
Initialize”. Choosing A1-03 = “1110: User Initialize” will reset all parameters to the values saved as user-set defaults.
Refer to A1-03: Initialize Parameters on page 95 for details on drive initialization.
Setting 0: No change (awaiting command)
Setting 1: Set User Initialize values
The current parameter settings are saved as user-set default for User Initialize. After o2-03 is set to 1 and the ENTER key
is pressed, the values are saved and the display returns to 0.
Setting 2: Clear User Initialize Values
All user-set defaults for “User Initialize” are cleared. After o2-03 is set to 2 and the ENTER key is pressed, the values are
erased and the display returns to 0.
n
o2-04: Drive Capacity Selection
Set this parameter when replacing the controller. For information on the drive model selection, refer to Defaults by Drive
Model Selection (o2-04) on page 87.
NOTICE: Drive performance will suffer if the correct drive capacity is not set for o2-04, and protective functions will fail to operate
properly.
Note: Change settings only when necessary.
n o2-05: Frequency Reference Setting Method Selection
Determines whether the ENTER key must be pressed after changing the frequency reference using the digital operator
while in the Drive Mode.
o2-01 b1-07 Switch from LOCAL to REMOTE Switch from REMOTE to LOCAL
0
0 Not possible Not possible
1 Not possible Not possible
1
0 Will not run until a new Run command is entered. Run not possible
1
If a Run command is entered, the drive will start
running as soon as the LO/RE key is pushed to
change from LOCAL to REMOTE.
Run not possible
No. Name Setting Range Default
o2-02 STOP Key Function Selection 0 or 1 1
No. Name Setting Range Default
o2-03 User Parameter Default Value 0 to 2 0
No. Name Setting Range Default
o2-04 Drive Capacity Selection – Determined by drive capacity
No. Name Setting Range Default
o2-05
Frequency Reference Setting Method
Selection
0, 1 0
MV1000ParameterGuide_E_conditional.book 234 ページ ２０１３年１０月１１日 金曜日 午後８時１８分
