2.10 o: Operator Related Settings
YASKAWA ELECTRIC TOEP C710687 03B FSDrive-MV1000 Parameter Guide 233
n o1-04: V/f Pattern Display Unit (CLV)
Determines the units used for the frequency reference when setting parameters that create the V/f pattern: E1-04, E1-06,
E1-07, E1-09, and E1-11. For motor 2, this includes parameters E3-04, E3-06, E3-07, E3-09, and E3-11.
Enabled only in CLV control mode.
When o1-04 = 1, this parameter is set in r/min units with the value in E2-04 as the number of motor poles.
Setting 0: Hz
Setting 1: r/min
Note: For motor 2, o1-04 can only be set to 0 for Hertz.
n o1-10: User-Set Display Units Maximum Value
Determines the display value that is equal to the maximum output frequency.
n
o1-11: User-Set Display Units Decimal Display
Determines how many decimal points should be used to set and display the frequency reference.
Setting 0: No decimal point
Setting 1: One decimal point
Setting 2: Two decimal points
Setting 3: Three decimal points
u o2: Digital Operator Keypad Functions
These parameters determine the functions assigned to the operator keys.
n
o2-01: LO/RE (LOCAL/REMOTE) Key Function Selection
Parameter o2-01 determines whether the LO/RE key on the digital operator will be enabled or not for switching between
LOCAL and REMOTE.
Setting 0: Disabled
The LO/RE key is disabled.
Setting 1: Enabled
The LO/RE switches between LOCAL and REMOTE operation. Switching is possible during stop only. When LOCAL
is selected, the LED indicator on the LO/RE key will light up.
WARNING! Sudden Movement Hazard. The drive may start unexpectedly if the Run command is already applied when switching
from LOCAL mode to REMOTE mode when b1-07 = 1, resulting in death or serious injury. Check all mechanical or
electrical connections thoroughly before making any setting changes to o2-01 and b1-07. Table 2.30 lists the setting
combinations for o2-01 and b1-07.
No.
<1> For details on the default settings, refer to Control Mode Dependent Parameter Default Values on page 84.
Name Setting Range Default
o1-04 V/f Pattern Display Unit 0 or 1 Determined by A1-02 <1>
No. Name Setting Range Default
o1-10 User-Set Display Units Maximum Value 1 to 60000 Determined by o1-03
No. Name Setting Range Default
o1-11 User-set Display Units Decimal Display 0 to 3 Determined by o1-03
No. Name Setting Range Default
o2-01 LO/RE Key Function Selection 0, 1 1
