A.2 Drive Specifications
YASKAWA ELECTRIC EZZ010928 FSDrive-MV1000 Instructions 183
A.2 Drive Specifications
Table A.3 Drive Specifications
Item Specifications
Efficiency
<1> Adjustments, e.g. to parameters, are required after auto-tuning.
<2> When the momentary power loss compensation function is used, an uninterruptible power supply unit for the control power supply is needed
(this is an option).
<3> To use the communications function, additional wiring and the installation of an option card must be done.
For Ethernet or CP-215 communication, an optional expansion PLC board is required.
<4> UL and cUL standards: A waiting approval.
Approx. 97% (At rated motor speed, 100% load)
Power Factor Min. 0.95 (At motor rated speed, 100% load)
Cooling Method Forced air-cooling by fan (with failure detection)
Control Specifications
Control Method
Open Loop Vector Control (OLV), Closed Loop Vector Control (CLV), V/f control (for multiple motor
operation), Closed Loop Vector Control for SM (optional)
Main Circuit
Voltage-type PWM control with multiple outputs connected in series
(Power Cell: 3-level output)
Frequency Control
Range
0.01 to 120 Hz
Frequency Control
Accuracy
±0.5%
Analog Input
Resolution
0.03 Hz
Accel/Decel Time 0.1 to 6000 s
Torque Accuracy <1> ±0.5% (OLV), ±3% (CLV)
Overload Tolerance Continuous rated current 100%, overload tolerance 110% for 1 minute and 120% for 15 seconds
Momentary Power
Loss Compensation
Time <2>
Max. 2 seconds
Main Control
Functions
Torque control, Droop control, Speed/torque control switch, Momentary power loss compensation, Speed
search, Overtorque detection, Torque limit, 17-step speed (max.), Accel/decel time switch, S-curve accel/decel,
Auto-tuning (rotational, stationary), Dwell, Cooling fan on/ off, Slip compensation, Torque compensation,
Frequency jump, Upper/lower limits for frequency reference, DC injection braking at start and stop, PID
control (with sleep function), MEMOBUS communication (RS-485, max. 115.2 kbps), Fault retry
Protective Functions
Overcurrent, Overvoltage, Undervoltage, Output ground fault, Output open-phase, Overload, Cooling-fan
error, Transformer overheat, Motor overheat, etc.
PLC Functions (Optional) Expansion PLC board
Standard Communication
Functions
RS-232: Digital operator
RS-485: MEMOBUS (Modbus)
USB: DriveWizard Plus MV
Communications
(Optional) <3>
Any one of PROFIBUS-DP, DeviceNet, Ethernet, or CP-215 can be installed.
Input Transformer Class H dry type, –5%/N/+5% tap, secondary multi-phase winding
Temperature Protection
Power Cells: protected by thermistor for temperature
Transformer: protected by thermometer PT100Ω
Maintainability/
Environmental
Specifications
Control Panel Status display, Fault display, Parameter setting, Parameter reference
Main Circuit Power Cell construction
Protection Design IP40 (simplified dustproof type)
Ambient
Temperature,
Relative Humidity
–5°C to +40°C, 85%RH max. (no condensing)
Storage Temperature –20°C to +60°C (for very short term when handling)
Atmosphere
General environmental conditions, free from dust and corrosive gases
Altitude: Max. 2000 m
Panel
Specifications
Painting 5Y7/1 semi-gloss both for inner and outer faces
Form Made of enclosing steel sheets, vertical standalone type, front maintenance type
Applicable Standards <4> –
