2.3 Dimensions
YASKAWA ELECTRIC EZZ010928 FSDrive-MV1000 Instructions 47
Mechanical Installation
2
2.3 Dimensions
The FSDrive-MV1000 series dimensions and approximate masses are shown below.
Table 2.10 Drive Dimensions and Approximate Masses
Voltage
Class
(kV)
<1> Side-by-side configurations comprising two or more drive panels
<2> Under development
<3> The dimensions and masses may be changed.
Model
CIMR-MV2
Dimensions (mm)
Approx. Mass
(kg) <3> <2>
Dimension
Drawing
No.
Width Depth Height Height Height
W D H H1 H2
2
A6AA052
Figure 2.15
1680 1050 2800 2550 250 2400
A6AA058 1680 1050 2800 2550 250 2400
A6AA077 1680 1050 2800 2550 250 2600
A6AA093 1680 1050 2800 2550 250 2600
A6AA102 1680 1050 2800 2550 250 2600
A6AA115 1680 1050 2800 2550 250 2800
A6AA135 1680 1050 2800 2550 250 2800
A6AA160
<1>
Figure 2.16
3500 1270 2500 2100 400 6000
A6AA180
<1> 3500 1270 2500 2100 400 6000
A6AA205
<2> ––––– –
A6AA220
<2> ––––– –
A6AA280
<2> ––––– –
A6AA330 <2> ––––– –
A6AA390
<2> ––––– –
A6AA440
<2> ––––– –
A6AA505 <2> ––––– –
A6AA550
<2> ––––– –
A6AA600
<2> ––––– –
4
DDA052
Figure 2.17
1680 1050 2800 2550 250 2400
DDA058 1680 1050 2800 2550 250 2400
DDA064 1680 1050 2800 2550 250 2400
DDA077 1680 1050 2800 2550 250 2600
DDA093 1680 1050 2800 2550 250 2600
DDA102 1680 1050 2800 2550 250 2600
DDA115 1680 1050 2800 2550 250 2800
DDA125 1680 1050 2800 2550 250 2800
DDA155
<1>
Figure 2.18
3500 1270 2500 2100 250 6000
DDA190
<1> 3500 1270 2500 2100 250 6000
DDA220
<2> ––––– –
DDA250
<2> ––––– –
DDA285 <2> ––––– –
DDA315
<2> ––––– –
DDA340
<2> ––––– –
DDA375
<2> ––––– –
DDA440 <2> ––––– –
DDA505
<2> ––––– –
DDA575
<2> ––––– –
DDA625 <2> ––––– –
