4.4 Keypad Operation
166 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
A - Drive Series
B - Maximum Applicable Motor Output
C - Rated Output Current
D - Software Version
E - Serial Number
◆ Write Automatically Backed-up Parameters to the Bypass
You can automatically back up parameters to the keypad connected to the bypass and write those parameters to a
different drive as specified by the settings of o3-06 [Auto Parameter Backup Selection] and o3-07 [Auto Parameter
Backup Interval].
Note:
• Set o3-06 = 1 [Auto Parameter Backup Selection = Enabled] in each bypass to which you will write the parameters.
• This operation is not available when the parameters in the keypad and the parameters on the other bypasses are set to the same values.
1. Connect the keypad to the bypass.
2. Push or to select [Yes] and then push .
3. Push or to select [Yes] and then push .
The keypad will show the “End” message when the write process is complete.

YASKAWA HV600 Specifications

General

Category	DC Drives
Series	HV600
Overload Capacity	150% for 60 seconds
Output Voltage	0 - Input Voltage
Enclosure	NEMA 1, NEMA 12
Communication	Ethernet/IP, Modbus, DeviceNet, Profibus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Control Method	Vector Control
