YASKAWA HV600 User Manual

Specifications
7
7.8 Drive Watt Loss
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 541
7.8 Drive Watt Loss
◆ 208 V Models
Table 7.19 Drive Watt Loss (NEMA Rating)
Bypass Model Drive Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
D002 to D010 2011 10.6 5.0 45 86 131
D016 2017 16.7 5.0 56 140 196
D024 2024 24.2 5.0 75 184 259
D030 2031 30.8 5.0 89 244 333
D046 2046 46.2 5.0 116 314 430
D059 2059 59.4 5.0 148 418 566
D074 2075 74.8 5.0 175 538 713
D088 2088 88 5.0 201 615 816
D114 2114 114 5.0 246 780 1026
D143 2143 143 5.0 244 937 1180
D169 2169 169 5.0 279 1132 1411
D211 2211 211 5.0 331 1321 1651
D273 2273 273 5.0 423 1821 2244
◆ 240 V Models
Table 7.20 Drive Watt Loss (NEMA Rating)
Bypass Model Drive Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
A002 to A009 2011 10.6 5.0 45 86 131
A015 2017 16.7 5.0 56 140 196
A022 2024 24.2 5.0 75 184 259
A028 2031 30.8 5.0 89 244 333
A042 2046 46.2 5.0 116 314 430
A054 2059 59.4 5.0 148 418 566
A068 2075 74.8 5.0 175 538 713
A080 2088 88 5.0 201 615 816
A104 2114 114 5.0 246 780 1026
A130 2143 143 5.0 244 937 1180
A154 2169 169 5.0 279 1132 1411
A192 2211 211 5.0 331 1321 1651
A248 2273 273 5.0 423 1821 2244
