Page #250 background imageLoading...
Page #250 background image
5.5 E: Motor Parameters
250 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
â–  E1-08: Mid Point A Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-08
(0307)
Mid Point A Voltage Sets a middle output voltage for the V/f pattern. Determined by o2-04
(208/240 V: 0.0 - 255.0 V,
480 V: 0.0 - 510.0 V)
Note:
Default setting is determined by o2-04 [Drive Model Selection].
â–  E1-09: Minimum Output Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-09
(0308)
Minimum Output Frequency Sets the minimum output frequency for the V/f pattern. 1.5 Hz
(Determined by E1-04)
â–  E1-10: Minimum Output Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-10
(0309)
Minimum Output Voltage Sets the minimum output voltage for the V/f pattern. 10.2 V
(208/240 V: 0.0 - 255.0 V,
480 V: 0.0 - 510.0 V)
â–  E1-11: Mid Point B Frequency
No.
(Hex.)
Name Description
Default
(Range)
E1-11
(030A)
Expert
Mid Point B Frequency Sets a middle output frequency for the V/f pattern. 0.0 Hz
(0.0 - E1-04)
Note:
Set this parameter to 0.0 to disable the function.
â–  E1-12: Mid Point B Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-12
(030B)
Expert
Mid Point B Voltage Sets a middle point voltage for the V/f pattern. 0.0 V
(208/240 V: 0.0 - 255.0 V,
480 V: 0.0 - 510.0 V)
Note:
Set this parameter to 0.0 to disable the function.
â–  E1-13: Base Voltage
No.
(Hex.)
Name Description
Default
(Range)
E1-13
(030C)
Expert
Base Voltage Sets the base voltage for the V/f pattern. 0.0 V
(208/240 V: 0.0 - 255.0 V,
480 V: 0.0 - 510.0 V)
Note:
• After Auto-Tuning, the value of E1-13 = E1-05 [Maximum Output Voltage].
• When E1-13 = 0.0, use the value of E1-05 to control the voltage.
â—† E2: Motor Parameters
E2 parameters [Motor Parameters] set induction motor data. To switch drive operation from one motor to another
motor, configure the first motor (motor 1).
