YASKAWA HV600 User Manual

Startup Procedure and Test Run
4
4.4 Keypad Operation
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 163
4. Push or to select [Data Logger], then push (Setup).
5. Push or to select [Log Sampling Interval], then push .
6. Push or to select the digit, then push or to change the value.
7. When you complete changing the value, push .
The procedure to set the sampling time is complete.
◆ Set Backlight to Automatically Turn OFF
You can set the backlight of the keypad screen to automatically turn OFF after a set length of time since the last key
operation on the keypad. The procedure in this section shows how to turn ON and turn OFF the backlight.
1. Push (Home) to show the HOME screen.
Note:
• The keypad will show [Home] in the top right corner when the HOME screen is active.
• If [Home] is not shown on , push (Back) to show [Home] on .
2. Push (Menu).

YASKAWA HV600 Specifications

General

Category	DC Drives
Series	HV600
Overload Capacity	150% for 60 seconds
Output Voltage	0 - Input Voltage
Enclosure	NEMA 1, NEMA 12
Communication	Ethernet/IP, Modbus, DeviceNet, Profibus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Control Method	Vector Control
