Electrical Installation
3
3.4 Main Circuit Terminal Wiring Procedure
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 91
A - Optional drive control wiring
B - Motor output circuit
C - Main input circuit
Figure 3.7 Narrow Bypass Wire Routing Example (Models H6BPD002 to D074 and B001 to B077)
◆ Enclosed Bypass Main Circuit Terminal Block Wiring Procedure
1.
Correctly ground the bypass terminal board.
2. Route the main circuit wiring. Figure 3.8 shows suggested wire entry and bending areas for the enclosure.
To Next Page
