YASKAWA HV600 User Manual

Parameter Details
5
5.10 o: Keypad-Related Settings
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 369
Sets the display of the time shown in the upper-left of the HOA keypad screen.
0 : 24 Hour Clock
1 : 12 Hour Clock
2 : 12 Hour JP Clock
■ o4-23: Date Format
No.
(Hex.)
Name Description
Default
(Range)
o4-23
(1550)
RUN
Date Format Sets the date display format. This parameter is only available on an HOA keypad. 2
(0 - 2)
Sets the date format that the drive uses for the fault history and other records.
0 : YYYY/MM/DD
1 : DD/MM/YYYY
2 : MM/DD/YYYY
Note:
The Fault History in the Monitor Mode shows when faults occurred. Refer to Show Fault History on page 153 for more information.
■ o4-24: bAT Detection Selection
No.
(Hex.)
Name Description
Default
(Range)
o4-24
(310F)
RUN
bAT Detection Selection Sets operation when the drive detects bAT [Keypad Battery Low Voltage] and TiM [Keypad Time Not
Set].
0
(0 - 2)
0 : Disable
The drive will not detect bAT or TiM.
1 : Enable (Alarm Detected)
TiM or bAT shows on the keypad, and operation continues. The output terminal set for Alarm [H2-01 to H2-03 = 10]
activates.
2 : Enable (Fault Detected)
The drive output shuts off and the motor coasts to stop. Fault relay output terminal MA-MC activates, and MB-MC
deactivates.
◆ o5: Log Function
The data log function saves drive status information as a CSV file in the microSD memory card in the keypad.
Monitors Ux-xx are the source of data log information. You can record a maximum of 10 monitors.
Change the HOA keypad screen from the main menu to the Diagnostic Tools screen and select the data log function.
Set the number of the monitor to record and the sampling time, then start to record the data log.
Table 5.52 Setting Parameters for Data Log Items
No. Name Default Data Log Monitors
o5-03 Log Monitor Data 1 101 U1-01 [Frequency Reference]
o5-04 Log Monitor Data 2 102 U1-02 [Output Frequency]
o5-05 Log Monitor Data 3 103 U1-03 [Output Current]
o5-06 Log Monitor Data 4 107 U1-07 [DC Bus Voltage]
o5-07 Log Monitor Data 5 108 U1-08 [Output Power]
o5-08 Log Monitor Data 6 000 Not selected
o5-09 Log Monitor Data 7 000 Not selected
o5-10 Log Monitor Data 8 000 Not selected
