5.10 o: Keypad-Related Settings
370 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
No. Name Default Data Log Monitors
o5-11 Log Monitor Data 9 000 Not selected
o5-12 Log Monitor Data 10 000 Not selected
Note:
• Do not de-energize the drive or disconnect the keypad from the drive during log transfer communication. A loss of connection can cause the
log function to fail after you restore power or connect the keypad
• You can use a microSDHC card that has a maximum of 32 GB capacity.
â– Log File Specifications
Item Specification
File storage location A folder called [Log_File] is created in the root directory of the micro SD card.
Filename GLOG0xxx.csv
Note:
[xxx] identifies a 3-digit decimal number
Maximum number of files
999 (GLOG0001.csv to GLOG0999.csv)
Character code ASCII code
Line break code <CR><LF>
Separating character [ , ] (Commas)
Header Rows First Row: Drive information including Drive Model, software version, control method, and sampling time
Second Row: Log data information including the monitor number, number decimal points, and unit code
â– Log File Configuration
The [Log_Files] folder is created in the root directory of the micro SD card. This is where the log data is stored as
CSV files. Log data files are created in this configuration. The number of rows changes when the number of selected
monitors change.
First row Drive information
Second row Log data information
Third row Log data 1
: Log data 2
: Log data 3
: :
Last row Log data n
First Row: Drive Information
This example shows the data text strings and data generated for the first row of log data.
Example of generated data: 00,0012,160107111230,GA800,VSAA09010,2,62,1000,000001
No. Item
Number of
Charac
ters
Example Description
1 Attribute 2 00 [00] shows that the record is a drive information record.
2 File number 4 0012 The [xxx] part of the [GLOG0xxx.csv] filename is a 3-digit decimal number in hexadecimal format.
Example filename of [GLOG0018.csv]: 018 (Dec.) = 0012 (Hex.)
3 Time stamp
*1
12 160107111230 Date file was generated
・Date: 20YY/MM/DD
・Time in 24-hour format: HH:MM:SS
Example data of [160107111230]: 11:12:30 on January 7, 2016
4 Model 5 GA800 Drive model information
5 Software number 9 VSAA09010 Drive software number
6 Control method 1 2 Setting value (Hex.) of A1-02 [Control Method Selection]
7 Drive capacity 2 62 Setting value (Hex.) of o2-04 [Drive Model Selection]
