5.7 H: Terminal Functions
260 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
5.7 H: Terminal Functions
H parameters are used to assign functions to external input and output terminals.
◆ H1: Digital Inputs
H1 Parameters set the MFDI terminal functions.
■ H1-01 to H1-07 Terminal S1 to S7 Function Selection
The drive has 7 MFDI terminals. Refer to Table 5.36 for drive default settings and functions.
Table 5.36 MFDI Default Settings and Functions
No. Name Default Function
H1-01 Terminal S1 Function Selection 40 Forward RUN (2-Wire)
H1-02 Terminal S2 Function Selection F Not Used
H1-03 Terminal S3 Function Selection 24 External Fault (NO-Always-Coast)
H1-04 Terminal S4 Function Selection 14 Fault Reset
H1-05 Terminal S5 Function Selection 3 Multi-Step Speed Reference 1
H1-06 Terminal S6 Function Selection 4 Multi-Step Speed Reference 2
H1-07 Terminal S7 Function Selection 6 Jog Reference Selection
Table 5.37 MFDI Setting Values
Setting Value Function Reference
3 Multi-Step Speed Reference 1
264
4 Multi-Step Speed Reference 2
264
5 Multi-Step Speed Reference 3
265
6 Jog Reference Selection
265
7 Accel/Decel Time Selection 1
265
8 Baseblock Command (N.O.)
265
9 Baseblock Command (N.C.)
265
A Accel/Decel Ramp Hold
266
B Overheat Alarm (oH2)
266
C Analog Terminal Enable Selection
266
F Not Used
266
14 Fault Reset Procedure
266
15 Fast Stop (N.O.)
266
17 Fast Stop (N.C.)
267
18 Timer Function
267
19 PID Disable
267
1B Programming Lockout
267
1E Reference Sample Hold
268
20 to 2F External Fault
268
30 PID Integrator Reset
269
31 PID Integrator Hold
269
34 PID Soft Starter Disable
269
35 PID Input (Error) Invert
269
3E PID Setpoint Selection 1
270
Setting Value Function Reference
3F PID Setpoint Selections 2
270
40 Forward RUN (2-Wire)
270
44 Add Offset Frequency 1 (d7-01)
270
45 Add Offset Frequency 2 (d7-02)
270
46 Add Offset Frequency 3 (d7-03)
270
51 Sequence Timer Disable
271
52 Sequence Timer Cancel
271
61 Speed Search from Fmax
271
62 Speed Search from Fref
271
63 Field Weakening
271
68 High Slip Braking (HSB) Activate
271
6A Drive Enable
272
70 Drive Enable 2
272
82 PI Switch to Aux
272
83 Dedicated Multi-Setpoint YA-02
272
84 Dedicated Multi-Setpoint YA-03
272
85 Dedicated Multi-Setpoint YA-04
273
88 Thermostat Fault
273
A8 PI2 Control Disable
273
AA PI2 Control Inverse Operation
273
AB PI2 Control Integral Reset
273
AC PI2 Control Integral Hold
273
AD Select PI2 Control PI Parameters
273
