YASKAWA HV600 User Manual

Parameter Details
5
5.6 F: Options
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 259
■ F7-17: EtherNet/IP Speed Scaling Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-17
(03F5)
EtherNet/IP Speed Scaling
Factor
Sets the scaling factor for the speed monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-18: EtherNet/IP Current Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-18
(03F6)
EtherNet/IP Current Scale
Factor
Sets the scaling factor for the output current monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-19: EtherNet/IP Torque Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-19
(03F7)
EtherNet/IP Torque Scale
Factor
Sets the scaling factor for the torque monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-20: EtherNet/IP Power Scaling Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-20
(03F8)
EtherNet/IP Power Scaling
Factor
Sets the scaling factor for the power monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-21: EtherNet/IP Voltage Scale Factor
No.
(Hex.)
Name Description
Default
(Range)
F7-21
(03F9)
EtherNet/IP Voltage Scale
Factor
Sets the scaling factor for the voltage monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-22: EtherNet/IP Time Scaling
No.
(Hex.)
Name Description
Default
(Range)
F7-22
(03FA)
EtherNet/IP Time Scaling Sets the scaling factor for the time monitor in the EtherNet/IP Class ID 2AH Object. 0
(-15 - +15)
■ F7-23 to F7-32: Dynamic Out Param 1 to 10 for CommCard
No.
(Hex.)
Name Description
Default
(Range)
F7-23 to F7-27
(03FB - 03FF)
F7-28 to F7-32
(0370 - 0374)
Dynamic Out Param 1 to 10
for CommCard
When you use an Ethernet/IP option, sets Output Assembly 116. The drive writes the values from
Output Assembly 116 to the MEMOBUS/Modbus address register that is stored for each parameter.
The drive will not write the values from Output Assembly 116 to the registers when the MEMOBUS/
Modbus address is 0. When you use a ProfiNet option, set F7-23 to F7-27 to configurable Output 1-
5.
0
■ F7-33 to F7-42: Dynamic In Param 1 to 10 for CommCard
No.
(Hex.)
Name Description
Default
(Range)
F7-33 to F7-42
(0375 - 037E)
Dynamic In Param 1 to 10
for CommCard
When you use an Ethernet/IP option, sets Input Assembly 166. The drive sends the values from the
MEMOBUS/Modbus address registers stored for each parameter to Input Assembly 166. The drive
returns the default register value for the option card when the MEMOBUS/Modbus address is 0 and
the value sent to Input Assembly 166 is not defined. When you use a ProfiNet option, set F7-33 to
F7-37 to configurable inputs 1-5.
0
