7.8 Drive Watt Loss
542 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
◆ 480 V Models
Table 7.21 Drive Watt Loss (NEMA Rating)
Bypass Model Drive Model
Rated Output
Current
A
Carrier Frequency
kHz
Interior Unit Loss
W
Cooling Fin Loss
W
Total Loss
W
B001 to B004 4005 4.8 5.0 36 39 75
B007 4008 7.6 5.0 45 63 108
B011 4011 11 5.0 56 142 198
B014 4014 14 5.0 66 196 262
B021 4021 21 5.0 89 212 301
B027 4027 27 5.0 112 285 397
B034 4034 34 5.0 128 327 455
B040 4040 40 5.0 145 373 518
B052 4052 52 5.0 178 470 648
B065 4065 65 5.0 224 600 824
B077 4077 77 5.0 271 819 1090
B096 4096 96 5.0 323 973 1295
B124 4124 124 5.0 423 1294 1717
B156 4156 156 5.0 332 1448 1780
B180 4180 180 5.0 395 1707 2102
B240 4240 240 5.0 406 1810 2216
B302 4302 302 5.0 866 2847 3712
