YASKAWA HV600 User Manual

Parameter Details
5
5.2 b: Application
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 219
3 : °F: Fahrenheit
4 : ft
3
/min: cubic feet/min
5 : m
3
/h: cubic meters/hour
6 : L/h: liters/hour
7 : L/s: liters/sec
8 : bar: bar
9 : Pa: Pascal
10 : °C: Celsius
11 : m: meters
12 : ft: feet
13 : L/min: liters/min
14 : m
3
/min: cubic meters/min
15 : "Hg: Inch Mercury
16 : kPa: kilopascal
48 : %: Percent
49 : Custom(b5-68~70)
50 : None
■ b5-42: PID Output 2 Calc Mode
No.
(Hex.)
Name Description
Default
(Range)
b5-42
(0161)
RUN
PID Output 2 Calc Mode Sets how to calculate the original PID output. 0
(0 - 3)
0 : Linear
The monitor displays PID output
Note:
When the PID output is 0, b5-45 [PID Out2 Monitor MIN for Linear] will set the minimum value. If the minimum value is set to be more
than or equal to the maximum value, U5-14 [PID Out2 Upr4 Digits] and U5-15 [PID Out2 Lwr4 Digits] will be limited to 0.
1 : Square Root
The monitor displays square root PID output
2 : Quadratic
The monitor displays 1/(PID output)
2
3 : Cubic
The monitor displays 1/(PID output)
3
Note:
Used for U5-14 and U5-15 only.
■ b5-43: PID Out2 Monitor MAX Upper4 Dig
No.
(Hex.)
Name Description
Default
(Range)
b5-43
(0162)
RUN
PID Out2 Monitor MAX
Upper4 Dig
Sets the upper 4 digits of the maximum monitor value. Used with b5-44 [PID Out2 Monitor MAX
Lower4 Dig] to set maximum monitor value of U5-14 [PID Out2 Upr4 Digits] and U5-15 [PID Out2
Lwr4 Digits] at maximum frequency.
0
(0 - 9999)
Note:
Used for U5-14 [PID Out2 Upr4 Digits] and U5-15 [PID Out2 Lwr4 Digits] only.
