Parameter Details
5
5.11 S: Special Applications
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 389
U5-20 will show only 0.
1 : Lower Limit (S3-10)
U5-20 will show the lower limit of the PI2 Control Output set with S3-10 [PI2 Control Output Lower Limit].
2 : Setpoint
U5-20 will show the target setpoint of the PI2 Control that aligns with U5-18 [PI2 Control Feedback].
â–  S3-13: PI2 Control Low Feedback Lvl
No.
(Hex.)
Name Description
Default
(Range)
S3-13
(3226)
RUN
PI2 Control Low Feedback
Lvl
Sets the secondary PI low feedback detection level. 0.00
(0.00 - 600.00)
Note:
Parameters S3-04 [PI2 Control Unit Selection], S3-03 [PI2 Control Decimal Place Pos], and S3-02 [PI2 Control Transducer Scale] set the
unit, resolution, and upper limit.
â–  S3-14: PI2 Control Low Feedback Time
No.
(Hex.)
Name Description
Default
(Range)
S3-14
(3227)
RUN
PI2 Control Low Feedback
Time
Sets the secondary PI low feedback detection delay time in seconds. 1.0 s
(0.0 - 25.5 s)
â–  S3-15: PI2 Control High Feedback Lvl
No.
(Hex.)
Name Description
Default
(Range)
S3-15
(3228)
RUN
PI2 Control High Feedback
Lvl
Sets the secondary PI high feedback detection level. 100.00
(0.00 - 600.00)
Note:
Parameters S3-04 [PI2 Control Unit Selection], S3-03 [PI2 Control Decimal Place Pos], and S3-02 [PI2 Control Transducer Scale] set the
unit, resolution, and upper limit.
â–  S3-16: PI2 Control High Feedback Time
No.
(Hex.)
Name Description
Default
(Range)
S3-16
(3229)
RUN
PI2 Control High Feedback
Time
Sets the secondary PI high feedback detection delay time in seconds. 1.0 s
(0.0 - 25.5 s)
â–  S3-17: PI2 Control Feedback Det Sel
No.
(Hex.)
Name Description
Default
(Range)
S3-17
(322A)
RUN
PI2 Control Feedback Det
Sel
Sets when the low and high feedback detection multifunction outputs (71h and 72h) for PI2 Control
are active.
0
(0, 1)
0 : While PI2 Control Enabled
Low and high feedback level detection are active only when PI2 Control is active.
1 : Always
Low and high feedback level detection are always active.
