5.11 S: Special Applications
402 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
bit 4 : Reserved
bit 5 : oL1 - Motor Overload
bit 6 : oL3 - Overtorque Detection 1
bit 7 : oL4 - Overtorque Detection 2
bit 8 : oL7 - High Slip Braking Overload
bit 9 : Reserved
bit 10 : UL3 - Undertorque Detection 1
bit 11 : UL4 - Undertorque Detection 2
bit 12 : UL6 - Motor Underload
bit 13 : Reserved
bit 14 : oS - Overspeed
bit 15 : dEv: Speed Deviation
Note:
The drive sets the bits in Hex.
■ S6-13: EMOVR Option Fault ON
No.
(Hex.)
Name Description
Default
(Range)
S6-13
(3244)
Expert
EMOVR Option Fault ON Sets the bit to enable fault detection during Emergency Override. 0
(0 - FFFF)
bit 0 : bUS - Option Communication
bit 1 : CE - Communication Error
bit 2 : E5 - SI-T3 Watch Dog Timer
bit 3 : EF0 - Option Card External Fault
bit 4 : PE1 - PLC Fault 1
bit 5 : PE2 - PLC Fault 2
bit 6 : nSE - Node Setup Error
bit 7 to 15 : Reserved
Note:
The drive sets the bits in Hex.
■ S6-14: EMOVR Application 1 Fault ON
No.
(Hex.)
Name Description
Default
(Range)
S6-14
(3245)
Expert
EMOVR Application 1 Fault
ON
Sets the bit to enable fault detection during Emergency Override. 0
(0 - FFFF)
bit 0 : EFx - External Faults
bit 1 : Reserved
bit 2 : HLCE - High Level Communications Error
bit 3 : bAT - HOA Keypad Battery Voltage Low
bit 4 : TiM - Keypad Time Not Set
bit 5 : bCE - Bluetooth Communication Fault
bit 6 : Reserved
bit 7 : Reserved
bit 8 : Reserved
bit 9 : MSL - Net Master Lost
