Parameter Details
5
5.13 Y: Application Features
YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 413
■ Y2-01: Sleep Level Type
No.
(Hex.)
Name Description
Default
(Range)
Y2-01
(3C64)
Sleep Level Type Sets the data source that the drive uses to know when to activate the Sleep Function. 5
(0 - 5)
0 : Output Frequency
1 : Output Current
2 : Feedback
3 : Output Speed (RPM)
5 : Output Frequency (non-PID)
Note:
• Feedback depends on PID direction operation.
• When the Sleep Function is active, the keypad will show the “Sleep” Alarm.
■ Y2-02: Sleep Level
No.
(Hex.)
Name Description
Default
(Range)
Y2-02
(3C65)
RUN
Sleep Level Sets the level that the level type set in Y2-01 [Sleep Level Type] must be at for the time set in Y2-03
[Sleep Delay Time] for the drive to enter Sleep Mode.
0.0
(0.0 - 6000.0)
When the monitor data of the level type set in Y2-01 is less than this level for longer than the time set in Y2-03, the
drive will enter Sleep Mode.
Note:
• When you set this parameter to 0.0, this function will not be active.
• This function is active only when the drive operates in AUTO Mode.
• When Y2-01 = 5 [Output Frequency (non-PID)], the drive will disable the Sleep function when you set this parameter to 0.0.
• When Y2-01 ≠ 5, the drive will set the sleep level to the largest value from d2-02 [Frequency Reference Lower Limit], Y1-06 [Minimum
Speed], and Y4-12 [Thrust Frequency] when you set this parameter to 0.0.
■ Y2-03: Sleep Delay Time
No.
(Hex.)
Name Description
Default
(Range)
Y2-03
(3C66)
RUN
Sleep Delay Time Sets the delay time before the drive enters Sleep Mode when the drive is at the sleep level set in Y2-
02 [Sleep Level].
5 s
(0 - 3600 s)
■ Y2-04: Sleep Activation Level
No.
(Hex.)
Name Description
Default
(Range)
Y2-04
(3C67)
RUN
Sleep Activation Level Sets the level above which the output frequency must increase to activate the Sleep Function when
Y2-01 = 0, 3, or 5 [Sleep Level Type = Output Frequency, Output Speed (RPM), or Output
Frequency (non-PID)].
0.0
(0.0 - 6000.0)
Note:
When you set this parameter to 0.0, this function will not be active, and the Sleep Function will activate above the minimum speed (largest
value from d2-02 [Frequency Reference Lower Limit], Y1-06 [Minimum Speed], and Y4-12 [Thrust Frequency]).
■ Y2-05: Sleep Boost Level
No.
(Hex.)
Name Description
Default
(Range)
Y2-05
(3C68)
RUN
Sleep Boost Level Sets the quantity of boost that the drive applies to the setpoint before it goes to sleep. 0.00%
(0.00 - 600.00%)
