Specifications

7.9 Drive Derating

YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 547

• Installing the bypass at 2000 m (6562 ft) or lower

• Installing the bypass between 2000 to 4000 m (6562 to 13123 ft) and grounding the neutral point on the power

supply.

If you do not ground the bypass with a neutral network, contact Yaskawa or your nearest sales representative.
