YASKAWA HV600 User Manual

2.8 Exterior and Mounting Dimensions
60 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Bypass
Model
H6B1
Dimensions
in (mm)
B001 B002 B003 B004 B007 B011 B014 B021 B027 B034 B040 B052 B065 B077 B096 B124 B156
W3
11.09
(282)
14.09
(358)
16.09
(409)
21.09
(536)
29.09
(739)
W4
3.75
(95)
4.50
(114)
6.50
(165)
4.00
(102)
9.00
(229)
W5
3.50
(89)
5.00
(127)
5.00
(127)
8.00
(203)
9.00
(229)
W6
6.75
(171)
6.75
(171)
6.75
(171)
8.00
(203)
10.00
(254)
W7
1.25
(32)
3.00
(76)
3.00
(76)
3.00
(76)
3.00
(76)
H1
24.61
(625)
32.61
(828)
35.82
(910)
40.82
(1037)
51.82
(1316)
H2
20.00
(508)
27.00
(686)
30.00
(762)
30.00
(762)
44.00
(1118)
D1
13.73
(349)
15.74
(400)
16.70
(424)
17.00
(432)
18.70
(475)
D2
28.415
(722)
33.420
(849)
36.42
(925)
41.720
(1060)
51.417
(1306)
D3
7.00
(178)
8.50
(216)
9.50
(241)
8.50
(216)
8.50
(216)
D4
5.00
(127)
5.00
(127)
5.00
(127)
5.00
(127)
8.00
(203)
D5
7.00
(178)
8.00
(203)
9.00
(229)
8.00
(203)
8.50
(216)
D6
1.50
(25)
3.00
(76)
3.00
(76)
3.00
(76)
8.00
(203)
D7
5.00
(127)
6.00
(152)
6.00
(152)
5.00
(127)
8.00
(203)
D8
4.00
(102)
5.00
(127)
6.00
(152)
7.00
(178)
8.50
(216)
Wt. (lb) 93 93 93 93 94 94 94 125 129 137 162 168 179 233 247 263 431
