9.11 L: Protection Functions

YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference 639

◆ L9: Drive Protection 2

No.

(Hex.)

Name Description

Default

(Range)

Ref.

L9-16

(11DC)

Expert

FAn1 Detect Time Sets the detection time for FAn1 [Drive Cooling Fan Fault]. Yaskawa recommends that

you do not change this parameter value.

4.0 s

(0.0 - 30.0 s)

346
