2.8 Exterior and Mounting Dimensions
64 YASKAWA SIEPYAIH6B01A HV600 AC Drive Bypass Technical Reference
Bypass Model
H6B1
Dimensions
in (mm)
A192 A248
D9
11.54
(293)
D10
17.00
(432)
D11
18.25
(464)
D12
11.25
(286)
Wt. (lb) 803 859
Table 2.10 Bypass Enclosed Model Enclosure Dimensions: 480 Vac
Bypass Model
H6B1
Dimensions
in (mm)
B180 B240 B302
W
37.75
(959)
H
87.01
(2210)
D
32.19
(818)
W1
35.25
(895)
W2
8.50
(216)
W3
2.62
(67)
W4
1.25
(32)
W5
1.12
(28)
W6
41.99
(1067)
W7
39.75
(1010)
W8
3.00
(76)
W9
9.75
(248)
H1
84.01
(2134)
H2
69.34
(1761)
D1
9.05
(230)
D2
33.53
(852)
D3
23.14
(588)
D4
65.23
(1657)
D5
17.00
(432)

YASKAWA HV600 Specifications

General

Category	DC Drives
Series	HV600
Overload Capacity	150% for 60 seconds
Output Voltage	0 - Input Voltage
Enclosure	NEMA 1, NEMA 12
Communication	Ethernet/IP, Modbus, DeviceNet, Profibus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	5-95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Control Method	Vector Control
