YASKAWA P1000

No.
(Addr.
Hex)
Name Description Values Page
F6-64 to
F6-71
(3DF to
3C8)
Reserved
Reserved for Dynamic I/O Assembly Parameters.
– –
F7-01
(3E5)
<2>
IP Address 1
Sets the most significant octet of network static IP address.
Default: 192
Range: 0 to 255
–
F7-02
(3E6)
<2>
IP Address 2
Sets the second most significant octet of network static IP address.
Default: 168
Range: 0 to 255
–
F7-03
(3E7)
<2>
IP Address 3
Sets the third most significant octet of network static IP address.
Default: 1
Range: 0 to 255
–
F7-04
(3E8)
<2>
IP Address 4
Sets the fourth most significant octet of network static IP address.
Default: 20
Range: 0 to 255
–
F7-05
(3E9)
Subnet Mask 1
Sets the most significant octet of network static Subnet Mask. Default: 255
Range: 0 to 255
–
F7-06
(3EA)
Subnet Mask 2
Sets the second most significant octet of network static Subnet Mask. Default: 255
Range: 0 to 255
–
F7-07
(3EB)
Subnet Mask 3
Sets the third most significant octet of network static Subnet Mask. Default: 255
Range: 0 to 255
–
F7-08
(3EC)
Subnet Mask 4
Sets the fourth most significant octet of network static Subnet Mask. Default: 0
Range: 0 to 255
–
F7-09
(3ED)
Gateway Address 1
Sets the most significant octet of network Gateway address. Default: 192
Range: 0 to 255
–
F7-10
(3EE)
Gateway Address 2
Sets the second most significant octet of network Gateway address. Default: 168
Range: 0 to 255
–
F7-11
(3EF)
Gateway Address 3
Sets the third most significant octet of network Gateway address. Default: 1
Range: 0 to 255
–
F7-12
(3E0)
Gateway Address 4
Sets the fourth most significant octet of network Gateway address. Default: 1
Range: 0 to 255
–
F7-13
(3F1)
Address Mode at Startup
Select the option address setting method
0: Static
<3>
1: BOOTP
2: DHCP
Default: 2
Range: 0 to 2
–
F7-14
(3F2)
Duplex Mode Selection
Selects duplex mode setting.
0: Half duplex forced
1: Auto-negotiate duplex mode and communication speed
2: Full duplex forced
Default: 1
Range: 0 to 2
–
F7-15
(3F3)
Communication Speed
Selection
Sets the communication speed
10: 10 Mbps
100: 100 Mbps
Default: 10
Range: 10, 100
–
F7-16
(3F4)
Communication Loss
Timeout
Sets the timeout value for communication loss detection in tenths of a second.
A value of 0 disables the connection timeout.
Example: An entered value of 100 represents 10.0 seconds.
Default: 0
Min.: 0
Max.: 300
–
F7-17
(3F5)
EtherNet/IP Speed Scaling
Factor
Sets the scaling factor for the speed monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-18
(3F6)
EtherNet/IP Current Scaling
Factor
Sets the scaling factor for the output current monitor in EtherNet/IP Class ID
2AH Object.
Default: 0
Min.: -15
Max.: 15
–
F7-19
(3F7)
EtherNet/IP Torque Scaling
Factor
Sets the scaling factor for the torque monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-20
(3F8)
EtherNet/IP Power Scaling
Factor
Sets the scaling factor for the power monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
F7-21
(3F9)
EtherNet/IP Voltage Scaling
Factor
Sets the scaling factor for the voltage monitor in EtherNet/IP Class ID 2AH
Object.
Default: 0
Min.: -15
Max.: 15
–
B.5 E: Motor Parameters
