YASKAWA P1000 User Manual

n
EMC Filters
Install the drive with the EMC filters listed in Table C.2 to comply with the EN61800-3 requirements.
Table C.2 EN61800-3 Filters
Drive Model
Filter Data (Manufacturer: Schaffner)
Type Rated Current (A) Weight (lb)
Dimensions
[W x D x H] (in)
Y x X (in) Figure
Three-Phase 200 V Class
2A0004
FS5972-10-07 10 2.6 5.6 × 1.8 × 13.0 4.5 × 12.3
1
2A0006
2A0008
2A0010
FS5972-18-07 18 2.9 5.6 × 1.8 × 13.0 4.5 × 12.3
2A0012
2A0018
FS5972-35-07 35 4.6 8.1 × 2.0 × 14.0 6.9 × 13.22A0021
2A0030
2A0040
FS5972-60-07 60 8.8 9.3 × 2.6 × 16.1 8.1 × 15.4
2A0056
2A0069
FS5972-100-35 100 7.5 3.5 × 5.9 × 13.0 2.6 × 10.0
2
2A0081
2A0110
FS5972-170-40 170 13.2 4.7 × 6.7 × 17.8 4.0 × 14.4
2A0138
2A0169
FS5972-250-37 250 25.8 5.1 × 9.5 × 24.0 3.5 × 19.6
2A0211
2A0250
FS5972-410-99 410 23.1 10.2 × 4.5 × 15.2 9.3 × 4.7
3
2A0312
2A0360
FS5972-600-99 600 24.3 10.2 × 5.3 × 15.2 9.3 × 4.7
2A0415
Three-Phase 400 V Class
4A0002
FS5972-10-07 10 2.7 5.6 × 1.8 × 13.0 4.5 × 12.3
1
4A0004
4A0005
4A0007
4A0009
FS5972-18-07 18 2.9 5.6 × 1.8 × 13.0 4.5 × 12.3
4A0011
4A0018
FS5972-35-07 35 4.6 8.1 × 2.0 × 14.0 6.9 × 13.24A0023
4A0031
4A0038
FS5972-60-07 60 8.8 9.3 × 2.6 × 16.1 8.0 × 15.44A0044
4A0058
4A0072
FS5972-100-35 100 16.5 3.5 × 5.9 × 13.0 2.6 × 10.0
2
4A0088
4A0103
FS5972-170-35 170 10.4 4.7 × 6.7 × 17.8 4.0 × 14.44A0139
4A0165
4A0208 FS5972-250-37 250 25.8 5.1 × 9.5 × 24.0 3.5 × 19.6
4A0250
FS5972-410-99 410 23.1 10.2 × 4.5 × 15.2 9.3 × 4.7
3
4A0296
4A0362
4A0414
FS5972-600-99 600 24.3 10.2 × 5.3 × 15.2 9.3 × 4.7
4A0515
4A0675 FS5972-800-99 800 69.4 11.8 × 6.3 × 28.2 10.8 × 8.3
C.1 European Standards
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
241
C
Standards Compliance

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
