YASKAWA P1000 User Manual

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0139
R/L1, S/L2, T/L3 3/0 1/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 2/0 1/0 to 4/0
⊖, ⊕1
– 1/0 to 4/0
⊕3
– 3 to 4/0
4 4
4A0165
R/L1, S/L2, T/L3 4/0 3/0 to 4/0
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 4/0 3/0 to 4/0
⊖, ⊕1
– 1 to 4/0
⊕3
– 1/0 to 4/0
4 4 to 2
4A0208
R/L1, S/L2, T/L3 300 2 to 300
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 300 2 to 300
⊖, ⊕1
– 1 to 250
⊕3
– 3 to 3/0
4 4 to 300
4A0250
R/L1, S/L2, T/L3 400 1 to 600
M10
18 to 23
(159 to 204)
U/T1, V/T2, W/T3 400 1/0 to 600
⊖, ⊕1
– 3/0 to 600
⊕3
– 1 to 325
2 2 to 350
4A0296
R/L1, S/L2, T/L3 500 2/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 500 2/0 to 600
⊖, ⊕1
– 3/0 to 600
⊕3
– 1 to 325 M10
18 to 23
(159 to 204)
2 2 to 350 M12
32 to 40
(283 to 354)
4A0362
R/L1, S/L2, T/L3 4/0 × 2P 3/0 to 600
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 2P 3/0 to 600
⊖, ⊕1
– 4/0 to 600
⊕3
– 3/0 to 600 M10
18 to 23
(159 to 204)
1 1 to 350 M12
32 to 40
(283 to 354)
4A0414
R/L1, S/L2, T/L3 300 × 2P 4/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 300 × 2P 4/0 to 300
⊖, ⊕1
– 3/0 to 300
⊕3
– 3/0 to 300
1 1 to 3/0
4A0515
R/L1, S/L2, T/L3 3/0 × 4P 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 4P 3/0 to 300
⊖, ⊕1
– 1/0 to 300
⊕3
– 1/0 to 300
1/0 1/0 to 300
4A0675
R/L1, S/L2, T/L3 300 × 4P 4/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 300 × 4P 4/0 to 300
⊖, ⊕1
– 1/0 to 300
⊕3
– 1/0 to 300
2/0 2/0 to 300
3.6 Main Circuit Wiring
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
61
3
Electrical Installation

YASKAWA P1000 Specifications

General

Operating Temperature	-10°C to +50°C (14°F to 122°F)
Cooling Method	Fan Cooled
Output Voltage	0-Input Voltage
Output Frequency	0-400 Hz
Frequency Range	0.1-400 Hz
Power Rating	0.4 kW to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overheat, Short Circuit, Ground Fault
Protection Features	Electronic Thermal Overload Protection
Communication	Modbus RTU
Communication Interface	RS-485
Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000m (3280ft) without derating
Enclosure Rating	IP20
