YASKAWA P1000 User Manual

Drive Model Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
4A0930
R/L1, S/L2, T/L3, R1/L11, S1/L21,
T1/L31
4/0 × 4P×2 3/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 4/0 × 4P×2 3/0 to 300
⊖, ⊕1
– 4/0 to 300
⊕3
– 4/0 to 300
3/0 3/0 to 250
4A1200
R/L1, S/L2, T/L3, R1/L11, S1/L21,
T1/L31
300 × 4P×2 4/0 to 300
M12
32 to 40
(283 to 354)
U/T1, V/T2, W/T3 300 × 4P×2 4/0 to 300
⊖, ⊕1
– 250 to 300
⊕3
– 4/0 to 300
4/0 4/0 to 250
<1> Install a GFCI when using this wire gauge in accordance with IEC/EN 61800-5-1.
<2>
Install a GFCI or use 10 mm
2
(AWG 8) copper wire when using this wire gauge in accordance with IEC/EN 61800-5-1.
Note: When connecting peripheral devices or options to terminals ⊖, ⊕1, ⊕3, B1, and B2, refer to the instruction manual for each device. For
more information, contact Yaskawa or your nearest sales representative.
n
Three-Phase 600 V Class
Table 3.5 Wire Gauge and Torque Specifications (Three-Phase 600 V Class)
Drive Model
Terminal
Recomm. Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening Torque
N·m (lb.in.)
5A0003
5A0004
5A0006
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
⊖, ⊕1, ⊕2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
5A0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
⊖, ⊕1, ⊕2
– 14 to 10
B1, B2 – 14 to 10
10 12 to 10
5A0011
R/L1, S/L2, T/L3 10 14 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 14 14 to 6
⊖, ⊕1, ⊕2
– 14 to 6
B1, B2 – 14 to 10
8 12 to 8 M5
2.0 to 2.5
(17.7 to 22.1)
5A0017
R/L1, S/L2, T/L3 10 10 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 10 10 to 6
⊖, ⊕1, ⊕2
– 10 to 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
8 12 to 8 M6
5.4 to 6.0
(47.8 to 53.1)
5A0022
R/L1, S/L2, T/L3 8 10 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 10 10 to 6
⊖, ⊕1, ⊕2
– 10 to 6
B1, B2 – 10 to 8
2.7 to 3.0
(23.9 to 26.6)
8 10 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
3.6 Main Circuit Wiring
62
YASKAWA ELECTRIC TOEP YAIP1U 01B YASKAWA AC Drive - P1000 Quick Start Guide
