YOKOGAWA EML500 Series User Manual

3-1
IM80B80T10E 21th Edition : Jul.1,2007-00
< 3.COMPONENTS >
3. Components
3.1 SystemConguration
EML 500
EML 500
EML 500
10
15
20
5
0
knots
10
15
20
5
0
knots
10
15
20
5
0
knots
10
15
20
5
0
knots
SPEED
17.5kt
T.MILES
12345.56nm
LR525-F
Flush-mount unit
LR523-D
Flush-mount unit
LR523-W
Desktop/wall-mount unit
LR523-F
Flush-mount unit
(with bezel)
LR525-W
Wall-mount unit
LR524-F
Flush-mount unit
LT501-F
Flush-mount unit
LD001A-F
Flush-mount unit
LD001A-W
Wall-mount unit
LT501-W
Wall-mount unit
LR524-W
Wall-mount unit
Master indicator
Speed indicator (dual axis) Speed indicator (Single axis)
Master unit
Dimmer box
GPS
(Optional)
Contact signal(2p max)
Photocoupler (8P max)
Analog speed output (2p max)
Power or system failure (4P max)
Speed limit (2P max)
Analog speed output (4P max)
Speed and distance data output (2P max)
100 to 230 V AC power supply
200P/nm
200P/nm
1V DC to 5V DC
Alarm contact
Alarm contact
4mA to 20mA
Digital signal
(NMEA0183)
ø35 F
For double-bottom hull
ø70 F
LV071A/LS571
ø48 F
LV052/LS541(single axis)
LS542 (dual axis)
LV033/LS591
ø35 F
For single-bottom hull
LV033/LS531
100 V AC to 230 V AC
Used for flush-mount speed
indicator or external dimmer
(in case of EL lighting)
Digital signal
(NMEA0183)
MHR120
Universal Data Display
MHR112
Assist Monitor
MHR110A
Universal Data Display
LN052
Junction
box
(Optional)
Seawater valve / Sensor
