YOKOGAWA EML500 Series User Manual

A-5
IM80B80T10E 21th Edition : Jul.1,2007-00
< Appendix >
Appendix 5 : List of Components
1. Master Unit (LT501)
No. Component Part Number
1 Master CPU unit V8308 WA
2
Swithing powaer supply : 24V OUTPUT
(For 100V AC to 220V AC specications)
5T164A194-02
3
Switching power supply : +5V and ±15V
(For 100V AC to 220V AC specications)
5T164A193-01
4 CABLE ASSY J11 V8308CY
5 CABLE ASSY J12 V8308CZ
6 CABLE ASSY J21 V8308DG
7 CABLE ASSY J22 V8308DH
8 FUSE FU3; 1A A1309EF
9 FUSE FU4; 2A A1311EF
2. Master Indicator (LR523)
No. Component Part Number
1 Display V8308WD
2 Processor V8308WB
3 Power supply V8303WC
4 Sheet key unit V8308AC
3. Speed Indicator (LR524)
No. Component Part Number
1 M.D.U. assembly V8308WE for CE V8308CQ
2 Step motor assembly V8308YA
3 EL plate 5T153A014-01
4 Dimmer (AC 100 V)
5T162B015-01
(with 5T161W168-04)
5 Dimmer (AC 220 V)
5T162B015-01
(with RNC32B223J)
4. Dual-indication Speed Indicator (LR525)
No. Component Part Number
1 M.D.U. assembly V8308WE
2 M.D.U. II assembly V8308WG
3 P.S.U. assembly V8308WH
4 EL plate 5T153A014-01
<When equipped with built -in dimmer>
5 Dimmer (100 V AC)
5T162B015-01
(with 5T161W168-04)
6 Dimmer (220 V AC)
5T162B015-01
(with RNC32B223J)
