YOKOGAWA YS1000 Series - LCD Maintenance Settings

87
IM 01B08B02-01EN
List of Parameters
List of Parameters
Preset PID Setting Display (PID TABLE)
Parameter Name Setting and Display Range Unit
Factory Default Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE CAS
SELECT
PROG
PPB1 Preset PID proportional band 1 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI1 Preset PID integral time 1 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD1 Preset PID derivative time 1 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB2 Preset PID proportional band 2 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI2 Preset PID integral time 2 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD2 Preset PID derivative time 2 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB3 Preset PID proportional band 3 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI3 Preset PID integral time 3 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD3 Preset PID derivative time 3 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB4 Preset PID proportional band 4 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI4 Preset PID integral time 4 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD4 Preset PID derivative time 4 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB5 Preset PID proportional band 5 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI5 Preset PID integral time 5 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD5 Preset PID derivative time 5 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB6 Preset PID proportional band 6 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI6 Preset PID integral time 6 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD6 Preset PID derivative time 6 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB7 Preset PID proportional band 7 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI7 Preset PID integral time 7 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD7 Preset PID derivative time 7 0 to 9999 s (second) 0 N/A N/A N/A R/W PPB8 Preset PID proportional band 8 0.1 to 999.9 % 999.9 N/A N/A N/A R/W
PTI8 Preset PID integral time 8 1 to 9999 s (second) 1000 N/A N/A N/A R/W PTD8 Preset PID derivative time 8 0 to 9999 s (second) 0 N/A N/A N/A R/W
