List of Parameters
<Engineering Parameters>
Configuration Display 1 (CONFIG1)
If you change the controller mode (CTL), each parameter will be initialized.
Parameter Name Setting and Display Range Unit
Factory Default
Value
Display and Setting Conditions
for Controller Mode
User
Set-
tings
YS1500
(SINGLE)
YS1700
(PROG)
SINGLE CAS
SELECT
PROG
SET Enable/Disable setting INHB: Setting impossible ENBL: Setting possible (Note1) INHB R/W R/W R/W R/W
CTL Controller mode selection
PROG: Programmable mode (Note 2)
SINGLE: Single-loop mode CAS: Cascade mode SELECT: Selector mode
SINGLE PROG R/W R/W R/W R/W
START Start mode
AUT: HOT start
M-COLD: Powerfailureduration<2sec.;HOTStart,Powerfailureduration≥2sec.;M-COLDstart
A-COLD: Power failure duration<2 sec.; HOT Start, Power failure duration≥2 sec.; A-COLD start
C-COLD: Power failure duration<2 sec.; HOT Start, Power failure duration≥2 sec.; C-COLD start
COLD: Power failure duration<2 sec.; HOT Start, Power failure duration≥2 sec.; COLD start
M-COLD R/W R/W R/W R/W
CYCL Control cycle 200 ms, 100 ms, 50 ms
200 ms
N/A N/A N/A
R
ATSEL Autoselector selection LOW: Lower output value, HIGH: Higher output value (LOW) (LOW) N/A N/A R/W R/W
FDSP Power-on initial display
LOOP1: LOOP 1 Display, LOOP2: LOOP 2 Display, MTR1: METER 1 Display, MTR2: METER
2 Display, TRND1: TREND1 Display, TRND2: TREND2 Display, TRND3: TREND 3 Display,
ALARM: ALARM Display, DUAL1: DUAL 1 Display, DUAL2: DUAL 2 Display
LOOP1 R/W R/W R/W R/W
LOOP1 LOOP 1 Display ON/OFF
OFF, ON (Note 3)
ON ON R/W R/W R/W R/W
LOOP2 LOOP 2 Display ON/OFF ON N/A R/W R/W R/W
MTR1 METER 1 Display ON/OFF ON ON R/W R/W R/W R/W
MTR2 METER 2 Display ON/OFF ON N/A R/W R/W R/W
TRND1 TREND 1 Display ON/OFF ON ON R/W R/W R/W R/W
TRND2 TREND 2 Display ON/OFF ON N/A R/W R/W R/W
TRND3 TREND 3 Display ON/OFF ON ON R/W R/W R/W R/W
ALARM ALARM Display ON/OFF ON ON R/W R/W R/W R/W
DUAL1 DUAL 1 Display ON/OFF ON N/A R/W R/W R/W
DUAL2 DUAL 2 Display ON/OFF ON N/A R/W R/W R/W
CAMLK Keylock for C/A/M mode change
UNLOCK, LOCK
UNLOCK R/W R/W R/W R/W
SVLK Keylock for SV change UNLOCK R/W R/W R/W R/W
MVLK Keylock for MV change UNLOCK R/W R/W R/W R/W
SCOCD
Selection of Current Output Circuit Diagnosis FAIL: D/A FALL in the event of an error, ALARM: OOP ALARM in the event of an error, OFF: No diagnosis
ALARM R/W R/W R/W R/W
Y3TP Analog output 3 current/voltage switching 4-20mA, 1-5V 1-5V N/A N/A N/A R/W
Y2S Analog output 2 selection
OFF: None, PV1: Process variable 1, SV1: Setpoint value 1, PV2: Process variable 2, SV2:
Setpoint value 2, MV: Manipulated output variable,X1: Analog input 1, X2: Analog input 2, X3:
Analog input 3, X4: Analog input4,X5:Analog input 5,X6: Analog input 6 (Note 4), X7:Analog
input 7 (Note 4), X8: Analog input 8 (Note 4)
MV R/W R/W R/W N/A
Y3S Analog output 3 selection SV1 R/W R/W R/W N/A
Y4S Analog output 4 selection (Note 4) R/W R/W R/W N/A
PROG User program name Alphanumeric character 8 digits (set by YSS1000) DEFAULT N/A N/A N/A R
REV System revision number Style number and Revision number of the product
S
x.xx R R R R
MCU Main CPU version number Main CPU version number Rx.xx.xx R R R R
DCU Display CPU version number Display CPU version number Rx.xx.xx R R R R
PARA MCU parameter version number MCU parameter version number Rx.xx.xx R R R R
COMP Compile version number Compile version number Rx.xx.xx N/A N/A N/A R
Note 1: When the SET parameter is set to “ENBL”, [STOP] will appear on the right of the display title, and the manipulated output and alarm output will be kept.
Note 2: “PROG” (User program name) is displayed only on YS1700.
Note 3: Loop1 is always displayed even if you set “OFF” for all lines. When you do not use TRND3, set it to “OFF”.
Note 4: This value is displayed only on YS1700 Basic type with expandable I/O.
*The values in () of YS1500/1700 factory default values mean the initial values when the controller mode is changed to the selector/cascade mode
