3
IM 01B08B02-01EN
4th Edition : Mar. 2018 YK
All Rights Reserved Copyright © 2014 Yokogawa Electric Corporation
Foreword
Thank you for purchasing the YS1000 series single-loop controller
(hereinafter referred to as “YS1000”).
This manual describes the basic functions and operation methods of
the YS1500/YS1700. Please read though this user’s manual carefully
before using the product.
Note that the manuals for the YS1500/YS1700 comprise the following
vedocuments:
● Printedmanual
Manual Name Manual Number
YS1500/YS1700 Operation Guide IM 01B08B02-01EN
This manual describes the basic operation methods.
Precautions on the Use of the YS1000 Series
This manual is always delivered even if ‘without
manuals’ was selected.
IM 01B08B02-91EN
● Electronicmanuals
Manual Name Manual Number
YS1500/YS1700 Operation Guide IM 01B08B02-01EN
This is identical to the printed manual.
YS1500/YS1700 User’s Manual IM 01B08B02-02EN
This manual describes the detailed functions and setting items. It
does not contain the user programs and communication functions.
YS1000 Series Communication Interface
User’s Manual
IM 01B08J02-01EN
This manual describes how to use YS1000 in Ethernet, serial, and
DCS-LCS communications.
YSS1000 Setting Software/YS1700
Programmable Function User’s Manual
IM 01B08K02-02EN
This manual describes how to use YSS1000 and YS1700’s
programmable function.
YS1000 Series Replacement Manual IM 01B08H02-01EN
This manual describes the compatibility of installation and wiring
with YS100, YS80, EBS, I, EK, HOMAC, and 100 line.
Precautions on the Use of the YS1000 Series
This manual is always delivered even if ‘without
manuals’ was selected.
IM 01B08B02-91EN
User’s manuals for YS1000 are available on the following web site:
www.yokogawa.com/ns/ys/im/
You need Adobe Reader 7.0 or later (but the latest version is
recommended) installed on the computer in order to open and read
the manuals.
The printed versions of the electronic manuals are available for
purchase. Contact your nearest YOKOGAWA dealer for details.
● GeneralSpecications
General Specification Name GS Number
YS1700 Programmable Indicating Controller GS 01B08B02-01EN
YS1500 Indicating Controller GS 01B08C02-01EN
*
Thelasttwocharactersofthemanualnumberandgeneralspecication
number indicate the language in which the manual is written.
Notice
● Thecontentsofthismanualaresubjecttochangewithout
notice as a result of continuing improvements to the instrument’s
performance and functions.
● Everye󰀨orthasbeenmadetoensureaccuracyinthepreparation
of this manual. Should any errors or omissions come to your
attention, however, please inform YOKOGAWA Electric’s sales
o󰀩ceorsalesrepresentative.
● Undernocircumstancesmaythecontentsofthismanual,inpart
or in whole, be transcribed or copied without our permission.
Trademarks
● Ourproductnamesorbrandnamesmentionedinthismanualare
the trademarks or registered trademarks of YOKOGAWA Electric
Corporation (hereinafter referred to as YOKOGAWA).
● Microsoft,MS-DOS,Windows,WindowsXP,andWindowsNT
are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
● Adobe,Acrobat,andPostscriptareeitherregisteredtrademarks
or trademarks of Adobe Systems Incorporated.
● EthernetisaregisteredtrademarkofXEROXCorporation.
● WedonotusetheTMor®marktoindicatethesetrademarksor
registered trademarks in this user's manual.
● Allotherproductnamesmentionedinthisuser'smanual
are trademarks or registered trademarks of their respective
companies.
Authorised Representative in the EEA
Yokogawa Europe BV. (Address: Euroweg 2, 3825 HD Amersfoort,
The Netherlands) is the Authorised Representative of Yokogawa
Electric Corporation for this Product in the EEA.
Revisions
1st Edition: June 2014
2nd Edition: May 2015
3rd Edition: Mar. 2016
4th Edition: Mar. 2018
Safety Precautions
Thefollowingcontentsarefor the su󰀩x codes “-
0
”, “-
1
” and
“-
2
This instrument is a product of Installation Category II of IEC/
EN61010-1, IEC/EN61010-2-201 and IEC/EN61010-2-030 Safety
Standards and Class A (use in commercial and industrial areas) of
EN61326-1, EN55011 (EMC Standards) (use a ferrite core and an
arrester to comply with the standards).
CAUTION
This instrument is a class A product (use in commercial and
industrial areas). In a domestic environment this product may
cause radio interference in which case the user needs to take
adequate measures.
This instrument is designed to be used within the scope of
Measurement Category O (other) and is dedicated for indoor use.
* Measurement Category O (other)
This category applies to electric equipment that measures a
circuit connected to a low-voltage facility and receives power from
stationary equipment such as electric switchboards.
To use the instrument properly and safely, observe the safety precautions
described in this user’s manual when operating it. Use of the instrument
in a manner not prescribed herein may compromise protection features
inherent in the device. We assume no liability for or warranty on a fault
caused by users’ failure to observe these instructions.
This instrument is an FM Non-incendive or CSA Non-incendive Standard
certiedproduct.
FM nonincendive: Class 3600:2011
Class 3611:2004
Class 3810:2005
Locations: Class I, Division 2, Groups A,B,C and D
Class I, Zone 2, Groups II C
Temperature Code: T4
CSA nonincendive: C22. 2 No. 213-M1987
CAN/CSA-C22.2 No. 0-10
CAN/CSA-C22.2 No. 0.4-04
Locations: Class I, Division 2, Groups A,B,C and D
Temperature Code: T4
