YOKOGAWA YS1000 Series User Manual

46
IM 01B08B02-01EN
Installation and Wiring
ExpandableI/OTerminal(YS010)
176
11
9
60
167
5
50
7
31.2
4
29.75
M4xL8
2-ø4.5
33.5
(When the DIN rail
mounting)
0909E.ai
Unit:mm
Weight: 260g
Figure 9.7
ExpandableI/OCable(YS011-03)
0910E.ai
Ground wiring: 1.25mm
2
, green
Length:500±50mm
R1.25-4
(95)
(70)
(40)
3000 ± 50mm
Weight: 320g
Figure 9.8
