SECTION 3 - HANDLING, STORAGE, AND INSTALLATION
FORM 102.20-N1
ISSUE DATE: 7/06/2016
3
FIGURE 34 - HOOD
LD116503
Additional Parts
The following parts may be used later in these instruc-
tions.
FIGURE 35 - DAMPER SHAFT EXTENSION KIT
(P/N 026-33715-002)
LD116504
LD16514
FIGURE 36 - CORNER CONNECTOR HOLE PLUG
(P/N 021-19568-000) (8)
FIGURE 37 - TOUCH-UP SPRAY - 12 OZ.
(P/N 013-03322-000)
LD116506
FIGURE 38 - SHIPPING SPLIT CORNER GASKET -
3.5 X 3. 5 (P/N 028-11883-010)
LD116507
FIGURE 39 - SPARE FAN BELT
LD116511
FIGURE 40 - CONDUIT (P/N 025-39024-001) AND
SJO CORD (P/N 025-35746-001)
