7 - 22 DS2208 Digital Scanner Product Reference Guide
Event Reporting
The host can request the scanner to provide certain information (events) relative to scanner behavior. Scan the
following bar codes to enable or disable the events listed in Table 7-4 and on the following pages.
Decode Event
Parameter # 256
SSI # F0h 00h
Scan one of the following bar codes to enable or disable Decode Event.
• Enable Decode Event - The scanner generates a message to the host upon a successful bar code decode.
• Disable Decode Event - No notification is sent.
Table 7-4 Event Codes
Event Class Event Code Reported
Decode Event Non-parameter decode 0x01
Boot Up Event System power-up 0x03
Parameter Event Parameter entry error 0x07
Parameter stored 0x08
Defaults set (and parameter event is enabled by default) 0x0A
Number expected 0x0F
Enable Decode Event
(1)
*Disable Decode Event
(0)
To Next Page
