5 - 2 DS2208 Digital Scanner Product Reference Guide
Scanning Sequence Examples
In most cases scanning one bar code sets the parameter value. For example, to enable signature capture, scan
the Enable Signature Capture bar code under Signature Capture on page 5-3. The digital scanner issues a fast
warble beep and the LED turns green, signifying a successful parameter entry.
Other parameters require scanning several bar codes. See the parameter descriptions for this procedure.
Errors While Scanning
Unless otherwise specified, to correct an error during a scanning sequence, just re-scan the correct parameter.
Signature Capture Preferences Parameter Defaults
Table 5-1 lists defaults for image capture preference parameters. Change these values in one of two ways:
•
Scan the appropriate bar codes in this chapter. The new value replaces the standard default value in
memory. To recall default parameter values, see Default Parameters on page 4-5.
•
Configure the scanner using the 123Scan
2
configuration program. See Chapter 12, 123Scan and Software
Tools.
NOTE See Appendix A, Standard Default Parameters for all user preference, host, symbology, and
miscellaneous default parameters.
See Appendix K, Signature Capture Code for signature capture code information.
Table 5-1 Signature Capture Preferences Parameter Defaults
Parameter
Parameter
Number
1
SSI
Number
2
Default
Page
Number
Signature Capture Preferences
Signature Capture 93 5Dh Disable
5-3
Signature Capture Image File Format
Selection
313 F0h 39h JPEG
5-4
Signature Capture Bits per Pixel (BPP) 314 F0h 3Ah 8 BPP
5-5
Signature Capture Width 366 F4h F0h 6Eh 400
5-6
Signature Capture Height 367 F4h F0h 6Fh 100
5-6
Signature Capture JPEG Quality 421 F0h A5h 65
5-6
1. Parameter number decimal values are used for programming via RSM commands.
2. SSI number hex values are used for programming via SSI commands.
