APPENDIX B COUNTRY CODES

Introduction

This chapter provides instructions for programming the keyboard to interface with a USB or keyboard wedge host.

The host powers the scanner. For host setup information, see Chapter 6, USB Interface and Chapter 10, Keyboard

Wedge Interface.

To select a code page for the country keyboard type, see Appendix B, Country Codes.

Throughout the programming bar code menus, default values are indicated with asterisks (

*).

*US English (North American)

Feature/Option

*Indicates Default
