Sample Bar Codes F - 7

Chinese 2 of 5

Matrix 2 of 5

Korean 3 of 5

NOTE Chinese 2 of 5 must be enabled to read the following bar code (see Chinese 2 of 5 on page 11-63).

45454545454

NOTE Matrix 2 of 5 must be enabled to read the following bar code (see Matrix 2 of 5 on page 11-63).

223344

NOTE Korean 2 of 5 must be enabled to read the following bar code (see Korean 3 of 5 on page 11-67).

1400230
