Zebra DS2208 Product Reference Guide

xvi DS2208 Digital Scanner Product Reference Guide
Related Product Line Configurations
The product configurations related to the DS2208 digital scanner are as follows.
Cables
The full list of supported cables can be found at:
https://partnerportal.zebra.com/PartnerPortal/product_services/downloads_z/barcode_scanners/Universal-Cable-
Guide-Bar-Code-Scanners.xlsx.
Chapter Descriptions
Topics covered in this guide are as follows:
• Chapter 1, Getting Started provides a product overview, unpacking instructions, and cable connection
information.
• Chapter 2, Data Capture provides beeper and LED definitions, techniques involved in scanning bar codes,
general instructions and tips about scanning, and decode ranges.
• Chapter 3, Maintenance & Technical Specifications provides suggested digital scanner maintenance,
troubleshooting, technical specifications, and signal descriptions (pinouts).
• Chapter 4, User Preferences & Miscellaneous Options describes each user preference feature and provides
programming bar codes for selecting these features.
• Chapter 5, Signature Capture Preferences describes signature capture preference features and provides
programming bar codes for selecting these features.
• Chapter 6, USB Interface describes how to set up the digital scanner with a USB host.
• Chapter 7, SSI Interface describes the system requirements of the Simple Serial Interface (SSI), which
provides a communications link between Zebra decoders and a serial host.
• Chapter 8, RS-232 Interface describes how to set up the digital scanner with an RS-232 host.
• Chapter 9, IBM 468X / 469X Interface describes how to set up the digital scanner with an IBM 468X/469X
host.
• Chapter 10, Keyboard Wedge Interface describes how to set up a keyboard wedge interface with the digital
scanner.
NOTES Check Solution Builder for additional information regarding all available accessories, and the latest
available configurations.
Table B: Accessories for the Digital Scanner
Product ID Description
20-71043-04R Gooseneck Intellistand - Black
STND-GS00UNC-04 Universal Gooseneck Intellistand – Black
21-71043-04R Cup (Black)
20-67176-01R Desktop Holder
11-66553-06R Wall Mount Holder

Zebra DS2208 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Connectivity technology	Wired
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS
Cables included	Micro-USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery life	100 h
Battery capacity	2400 mAh
Power consumption	250 mA
Power source type	DC
AC adapter output voltage	5 V
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	66 mm
Height	165 mm
Weight	161.6 g
