Zebra DS2208

To Next Page

To Previous Page

Symbologies 11 - 67

Korean 3 of 5

Parameter # 581

SSI # F1h 45h

Scan one of the following bar codes to enable or disable Korean 3 of 5.

NOTE The length for Korean 3 of 5 is fixed at 6.

Enable Korean 3 of 5

(1)

*Disable Korean 3 of 5

(0)
