Symbologies 11 - 17
UPC/EAN/JAN Supplemental AIM ID Format
Parameter # 672
SSI # F1h A0h
If Transmit Code ID Character on page 4-28 is set to AIM Code ID Character, scan one of the following bar codes to
select an output format when reporting UPC/EAN/JAN bar codes with supplementals:
•
Separate - Transmit UPC/EAN/JAN with supplementals with separate AIM IDs but one transmission, i.e.,
]E<0 or 4><data>]E<1 or 2>[supplemental data]
•
Combined – Transmit UPC/EAN/JAN with supplementals with one AIM ID and one transmission, i.e.,
]E3<data+supplemental data>
•
Separate Transmissions - Transmit UPC/EAN/JAN with supplementals with separate AIM IDs and separate
transmissions, i.e.,
]E<0 or 4><data>
]E<1 or 2>[supplemental data]
Separate
(0)
*Combined
(1)
Separate Transmissions
(2)
