11 - 86 DS2208 Digital Scanner Product Reference Guide

Decode Data Matrix Mirror Images

Parameter # 537

SSI # F1h 19h

Scan one of the following bar codes to select an option for decoding mirror image Data Matrix bar codes:

• Never - Do not decode Data Matrix bar codes that are mirror images.

•Always - Decode only Data Matrix bar codes that are mirror images.

•Auto - Decode both mirrored and unmirrored Data Matrix bar codes.

Never

(0)

Always

(1)

*Auto

(2)
