Zebra DS2208 Product Reference Guide

A - 2 DS2208 Digital Scanner Product Reference Guide
Continuous Bar Code Read 649 F1h 89h Disable 4-20
Unique Bar Code Reporting 723 F1h D3h Enable 4-20
Decode Session Timeout 136 88h 9.9 Seconds 4-21
Hands-Free Decode Session Timeout 400 F0 90 15 4-21
Timeout Between Decodes, Same
Symbol
137 89h 0.5 Seconds 4-22
Timeout Between Decodes, Different
Symbols
144 90h 0.1 Seconds 4-22
Decode Mirror Images (Data Matrix
Only)
537 F1h 19h Auto 4-23
Mobile Phone/Display Mode N/A N/A N/A 4-23
PDF Prioritization 719 F1h CFh Disable 4-24
PDF Prioritization Timeout 720 F1h D0h 200 ms 4-24
Decoding Illumination 298 F0h 2Ah Enable 4-25
Illumination Brightness 669 F1h 9Dh High 4-25
Low Light Scene Detection 810 F2h 2Ah Dim Illumination Low Light
Assist Scene Detection
4-26
Motion Tolerance (Hand-Held Trigger
Mode Only)
858 F2h 5Ah Less 4-27
Miscellaneous Options
Enter Key N/A N/A N/A 4-27
Tab Key N/A N/A N/A 4-28
Transmit Code ID Character 45 2Dh None 4-28
Prefix Value 99, 105 63h, 69h 7013 <CR><LF> 4-29
Suffix 1 Value
Suffix 2 Value
98, 104
100, 106
62h, 68h
64h, 6Ah
7013 <CR><LF> 4-29
Scan Data Transmission Format 235 EBh Data As Is 4-30
FN1 Substitution Values 103, 109 67h, 6Dh 7013 <CR><LF> 4-32
Transmit “No Read” Message 94 5E Disable 4-33
Unsolicited Heartbeat Interval 1118 F8h 04h 5Eh Disable 4-34
Table A-1 Parameter Defaults (Continued)
Parameter
Parameter
Number
SSI Number Default
Page
Number

Zebra DS2208 Specifications

General

Type	Handheld bar code reader
Wavelength	645 nm
Sensor type	LED
Scanner type	1D/2D
Pitch reading angle	-65 - 65 °
Motion tolerance (cm/s)	13
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 39, Code 93, EAN-13, GS1 DataBar Expanded, Interleaved 2 of 5, MSI, U.P.C.
Optical sensor resolution (W x H)	640 x 480 pixels
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
Standard interfaces	USB, RS-232, RS-485, Keyboard wedge
Connectivity technology	Wired
Certification	EN 60950-1 2ed + A11 + A1 + A12 + A2:2013, IEC 60950-1 2ed + A1 + A2, UL 60950-1, CAN/CSA-C22.2 No. 60950-1-07 IEC 62471 EN 55022 (Class B); EN 55032 (Class B) EN 55024 EN 61000-3-2 EN 61000-3-3 47 CFR Part 15, Subpart B, Class B ICES-003 Issue 6, Class B
Product color	Black
LED indicators	Yes
Housing material	-
International Protection (IP) code	IP42
Sustainability certificates	RoHS
Cables included	Micro-USB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Battery life	100 h
Battery capacity	2400 mAh
Power consumption	250 mA
Power source type	DC
AC adapter output voltage	5 V
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	99 mm
Width	66 mm
Height	165 mm
Weight	161.6 g
